Summary

A honeypot is a deceptive system or service set up to attract attackers. It mimics real targets but is isolated and monitored, allowing defenders to study attacks without risking real assets.

Purpose:

• Detect unauthorized or malicious activity
• Collect malware, attack tools, and TTPs
• Analyze attacker behavior and intent
• Distract attackers from real assets

Types:

Type	Interaction Level	Use Case
Low	Simulated responses	Scanning/bot detection (e.g., Honeyd)
Medium	Some real service logic	Basic exploitation (e.g., Cowrie, Dionaea)
High	Full real OS or apps	Advanced attacker research (custom VM, Honeynet)

Core Components:

• Fake services (SSH, FTP, SMB, HTTP)
• Logging system (Syslog, ELK, Splunk)
• Network traffic capture (tcpdump, Zeek)
• Out-of-band monitoring (so attacker can’t detect)

Monitoring Includes:

• Login attempts
• Uploaded files/malware
• Commands executed
• Network traffic (internal + external)

Risks:

• Attacker may use honeypot to pivot if not isolated
• Legal/ethical implications (especially in high-interaction traps)
• Must not interfere with legitimate infrastructure

---

SKILLS YOU NEED

• Basic Linux administration
• Python/Bash scripting
• Networking (TCP/IP, DNS, HTTP)
• Virtualization or cloud platform usage
• Log management (ELK, Splunk, etc. optional)
• Firewall (iptables/nftables)
• T-Pot

---

STEPS TO BUILD A FUNCTIONAL HONEYPOT

1. Choose Honeypot Type

Decide between:

• Low-Interaction – Simulates services (e.g., Cowrie, Honeyd)
• Medium-Interaction – More realistic but isolated (e.g., Dionaea)
• High-Interaction – Full OS emulation (dangerous but effective, e.g., custom VM)

2. Setup Environment (VM or Cloud)

• Use VirtualBox, VMware, or cloud instances (e.g., AWS with security groups locked down).
• Isolate the honeypot network: use NAT or VLAN segmentation.
• OS: Debian minimal install preferred for simplicity.

3. Install Honeypot Software

Option A: Cowrie (SSH/Telnet honeypot – low/medium interaction)

sudo apt update
sudo apt install git python3-venv python3-pip -y
git clone https://github.com/cowrie/cowrie.git
cd cowrie
python3 -m venv cowrie-env
source cowrie-env/bin/activate
pip install --upgrade pip
pip install -r requirements.txt
cp etc/cowrie.cfg.dist etc/cowrie.cfg

Edit config to set port, fake credentials, logging output.

Run it:

bin/cowrie start

Option B: Dionaea (malware collection – SMB, FTP, HTTP emulation)

sudo apt install dionaea -y

Configure /etc/dionaea/dionaea.conf for IPs/ports.

Option C: Custom High-Interaction (real OS honeypot)

• Deploy a real OS in a VM, e.g., Debian or Arch Server.
• Expose vulnerable services (RDP, SMB, open shares).
• Use Sysmon + ELK/Fluentbit to log everything.
• Monitor via Velociraptor or OSQuery.

4. Logging & Monitoring

• Forward logs to:
  • ELK Stack
  • Splunk
  • Graylog
  • Or even simple rsyslog to a logging server

Use Filebeat or Fluentbit to forward logs.

5. Network Traffic Capture

Use tcpdump, Wireshark, or Zeek:

sudo tcpdump -i any -w /var/log/honeypot/capture.pcap

6. Firewall Rules (to control & log)

Block all outbound unless needed:

iptables -A OUTPUT -p tcp --dport 80 -j DROP
iptables -A OUTPUT -p tcp --dport 443 -j DROP

Allow honeypot ports only:

iptables -A INPUT -p tcp --dport 22 -j ACCEPT

7. Deploy to Internet

Use cloud VPS (DigitalOcean, AWS, etc.) or port forward through home router.

⚠️ Ensure isolated logging and out-of-band access, so attackers can’t detect or disable your logs.

---

HOW TO USE EFFECTIVELY

• Log Everything: Don’t just collect hits. Record sessions, file uploads, commands.
• Tag IPs: Correlate IPs with abuse lists (AbuseIPDB, GreyNoise, etc.).
• Threat Analysis: Use sandbox (e.g., Cuckoo, Any.run) to analyze dropped binaries.
• Replay Attacks: Mimic what the attacker did in a sandbox or honeynet for deeper insight.
• Automate Reports: Use Python or ELK dashboards to generate daily summaries.
• Integrate with SIEM if used in prod.

---

EXTRA TIPS

• Cowrie + Suricata + Zeek = good stack
• Use canary tokens (e.g., Thinkst) for early detection
• Deploy in multiple regions/IPs to attract diverse attacks
• Rotate or rebuild weekly to stay fresh
